75mm ductwork
Ubbink Air Excellent 75 mm Ductwork
Slide title
Write your caption here
Button
Slide title
Write your caption here
Button
Slide title
Write your caption here
Button
Radial ductwork systems differ from traditional trunk and branch ductwork systems by running ducts between a distribution box and each habitable and wet room. The distribution box is then connected to a ventilation unit using mass flow ductwork and a silencer. The system pressure drop is lower as a result.
Continuous duct runs with mechanical connections at either end also mean less air leakage. The ventilation rates can be controlled by flow restrictors in the distribution box.
Cross-talk between rooms is reduced to an absolute minimum
The Air Excellent circular ductwork ensures efficient air distribution between distribution boxes and the various rooms.
Due to its circular shape, the Air Excellent ductwork can be installed easily and ensures keeping pressure losses to a minimum.
Features & Benefits
Lightweight
Easy and quick to install
Strong outer surface for damage-free installation
Smooth inner surface for less pressure drop and a long-term clean system
